esp MAGDUOSW Ceiling sounder for MAGDUO (white)
Image is for illustrative purposes only

esp MAGDUOSW Ceiling sounder for MAGDUO (white)

Part: MAGDUOSW
Need this part urgently: we advise you to check the stock availability for this item by contacting our sales team on 01482 589015
Description
Downloads
  • Ceiling mount sounder
  • Volume level adjustment
  • Built-in End of Line function
  • Device wiring base included

Dimensions (mm):ø105 x 72
Maximum Device Loading Units (DLU’s):36
Warranty (Years):3
Operating Voltage (Mains Powered Panel)(V DC):25.5 - 35
Operating Voltage (Battery Powered Panel)(V DC):20 - 26
Maximum Cable Size (mm²):1.5
Current Consumption (Quiescent)(mA):0.92
Current Consumption in alarm state (mA):10
Maximum Current Consumption:10mA
Wiring Type:2-Wire Conventional
Sound Output @ 1m (db):90+
Ingress Protection:IP21C
Operating Temperature (°C):-10 to +50
Compatible Products:Compatible with MAGDUO2, MAGDUO4 and MAGDUO8
Standards:BS EN 54-3
