Dimensions (mm): | 89 x 89 x 62 (Surface); 89 x 89 x 34 (Flush) |
Volume Modes: | 2 (Low & High) |
Device Loading Units (DLU’s) - Low: | 13 |
Warranty (Years): | 3 |
Operating Voltage (Mains Powered Panel)(V DC): | 25.5 - 35 |
Operating Voltage (Battery Powered Panel)(V DC): | 22 - 26 |
Maximum Cable Size (mm²): | 1.5 |
Current Consumption (Quiescent)(mA): | 0.185 |
Current Consumption in alarm state (mA): | High 14.5, Low 12.6 |
Maximum Current Consumption: | 14.5mA |
Wiring Type: | 2-Wire Conventional |
Sound Output @ 1m (Low) (db): | 65+ |
Sound Output @ 1m (High) (db): | 85+ |
Ingress Protection: | IP21C |
Operating Temperature (°C): | -10 to +50 |
Compatible Products: | Compatible with MAGDUO2, MAGDUO4 and MAGDUO8 |
Standards: | BS EN 54-3 |
