Blauberg TURBO-E-100 In-line mixed flow extractor fan - 100mm, standard

Part: TURBO-E-100
Need this part urgently: we advise you to check the stock availability for this item by contacting our sales team on 01482 589015
Description
Downloads

Features:

  • Highly efficient range of mixed flow extractor fans.
  • The range covers 4, 5 & 6" (100, 125 & 150mm) duct diameter sizes.
  • Supplied with or without a run-on timer.
  • Airflows up to 520 m3/hour - 144 l/second.
  • 5 Year Blauberg warranty.
  • Casing made of low-flammable polypropylene.
  • Designed to fit all standard duct sizes.
  • 2-speed German ball bearing motors used.
  • Can be installed anywhere in a ducted ventilation systems.
  • Equipped with thermal overload protection.

Impeller Type :Mixed Flow
Motor Type :AC
Electrical Supply :1 Phase 220/250 50/60Hz
Please choose Size :100mm Dia
Maximum Airflow Rate (l/s) :61 l/sec
Maximum Airflow Rate (m3/h) :220 m3/hour
Ingress Protection (IP) Rating :IP X4
Control Options :Standard
Duct Connection Size :100mm Diameter
Energy Rating :ERP 2018
