B.E.G. 92681
Image is for illustrative purposes only

B.E.G. 92681 (TS-DD) Time Switch DIN-rail (TH35), White IP54 TS 1 Channel

Part: 92681
Need this part urgently: we advise you to check the stock availability for this item by contacting our sales team on 01482 589015
Description
Downloads
  • Photoelectric switch set for DIN rail
  • LED adjustment aid (without delay) for adjustment of the switch-on threshold
  • Electronic component for installation onto DIN rail for convenient adjustment in the control cabinet
  • Switches off at around 1.3 times the activation value
  • Separate light sensor for surface or flush installation (included)

Nominal voltage :230V
Mounting method :Surface mounted
Colour :White
Halogen free :Yes
Contacts :1 make contact (NO)
Surface protection :Untreated
Switching-on delay :8 s
Switch-off delay :40 s
Material qualifier :Other
Max. switching current (resistive load) :4.3A
Max. switching power :1000W
Material :Plastic
RAL-number (similar) :7047
Transparent :No
Surface finish :Glossy
Degree of protection (IP rating) :IP54
