Aurora AU-LEDD1012
Image is for illustrative purposes only

Aurora AU-LEDD1012 Aurora 10W Dimmable 12V Constant Voltage Driver

Part: AU-LEDD1012
Need this part urgently: we advise you to check the stock availability for this item by contacting our sales team on 01482 589015
Description

10W Dimmable 12V DC Constant Voltage LED Driver. Dimmable LED driver for use with Aurora Premium, Standard and Contractor 12V dimmable LED lamps. LED lamps must have more than one LED to allow dimming. Dimmable with AU-DSP dimmers (de-rated to 50% loading). Overload protection/Short-circuit protection/Thermal protection. 1.0kV SURGE PROTECTION – EN 61547. Safety compliance – EN 61347. EMC compliance – EN 55015, EN 61000, EN 61547. 3 year warranty.

  • 3 Year Warranty
  • Parallel wiring only
  • EMC compliance – EN 55015, EN 61000, EN 61547
  • Safety compliance – EN 61347
  • 1.0kV SURGE PROTECTION – EN 61547
  • No junction box required
  • Integrated earth terminal for earth continuity
  • Loop-in, loop-out primary wiring terminals
  • Secondary wiring terminals - 1 output
  • Thermal protection

Protection class :II
Width :40mm
Height :27mm
Housing :Other
Length :145mm
Output voltage :12V
Degree of protection (IP rating) :IP20
IFTTT support available :No
Compatible with Apple HomeKit :No
Compatible with Google Assistant :No
Compatible with Amazon Alexa :No

Make an enquiry

...
